    Vishay Semiconductor Opto Division ILQ615-2

    !
    Last Time Buy — Production Ending
    The manufacturer is winding down production of this part. Once allocation closes, stock becomes hard to find — check availability while it lasts.
    Check availability
    Part No.:
    ILQ615-2
    Manufacturer:
    Vishay Semiconductor Opto Division
    Category:
    Transistor, Photovoltaic Output Optoisolators
    Package:
    16-DIP (0.300", 7.62mm)
    Datasheet:
    ODK (HK) Electronics Technology Co., LimitedILQ615-2.pdf
    Description:
    OPTOISO 5.3KV 4CH TRANS 16DIP
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Inventory:1,000

    Please send an inquiry. Send us your inquiry, and we will respond immediately.

    Part Number
    Quantity*
    Price
    Name*
    Company*
    Email*
    Comments
    • Specifications
    • FAQ
    • Product Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Vishay Semiconductor Opto Division
    Series:
    -
    Package/Case:
    16-DIP (0.300", 7.62mm)
    Packaging:
    Tube
    Product Status:
    Last Time Buy
    Number of Channels:
    4
    Voltage - Isolation:
    5300Vrms
    Current Transfer Ratio (Min):
    63% @ 10mA
    Current Transfer Ratio (Max):
    125% @ 10mA
    Turn On / Turn Off Time (Typ):
    3µs, 2.3µs
    Rise / Fall Time (Typ):
    2µs, 2µs
    Input Type:
    DC
    Output Type:
    Transistor
    Voltage - Output (Max):
    70V
    Current - Output / Channel:
    50mA
    Voltage - Forward (Vf) (Typ):
    1.15V
    Current - DC Forward (If) (Max):
    60 mA
    Vce Saturation (Max):
    -
    Grade:
    -
    Qualification:
    -
    Operating Temperature:
    -55°C ~ 100°C
    Mounting Type:
    Through Hole
    Supplier Device Package:
    16-DIP
