    STMicroelectronics L6398D

    Part No.:
    L6398D
    Manufacturer:
    STMicroelectronics
    Category:
    Gate Drivers
    Package:
    8-SOIC (0.154", 3.90mm Width)
    Datasheet:
    ODK (HK) Electronics Technology Co., LimitedL6398D.pdf
    Description:
    IC GATE DRVR HALF-BRIDGE 8SO
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Inventory:3,525

    Please send an inquiry. Send us your inquiry, and we will respond immediately.

    Part Number
    Quantity*
    Price
    Name*
    Company*
    Email*
    Comments
    • Specifications
    • FAQ
    • Product Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    STMicroelectronics
    Series:
    -
    Package/Case:
    8-SOIC (0.154", 3.90mm Width)
    Packaging:
    Tube
    Product Status:
    Active
    Programmable:
    Not Verified
    Driven Configuration:
    Half-Bridge
    Channel Type:
    Independent
    Number of Drivers:
    2
    Gate Type:
    IGBT, N-Channel MOSFET
    Voltage - Supply:
    10V ~ 20V
    Logic Voltage - VIL, VIH:
    1.1V, 1.9V
    Current - Peak Output (Source, Sink):
    290mA, 430mA
    Input Type:
    Inverting, Non-Inverting
    High Side Voltage - Max (Bootstrap):
    600 V
    Rise / Fall Time (Typ):
    75ns, 35ns
    Operating Temperature:
    -40°C ~ 150°C (TJ)
    Grade:
    -
    Qualification:
    -
    Mounting Type:
    Surface Mount
    Supplier Device Package:
    8-SOIC
