onsemi BFL4001-1EX

Name: BFL4001-1EX
Brand: onsemi
SKU: BFL4001-1EX

< >

Compare

Part No.:: BFL4001-1EX

Manufacturer:: onsemi

Category:: FETs, MOSFETs

Package:: TO-220-3 Full Pack

Description:: MOSFET N-CH 900V 6.5A TO220-3 FP

Quantity:: RFQ Add To RFQ list

Payment:

Shipping:

Inventory:8,548

Please send an inquiry. Send us your inquiry, and we will respond immediately.

Specifications
FAQ
Product Comparison
Tags

Product attributes: Attribute value

Manufacturer:: onsemi

Series:: -

Package/Case:: TO-220-3 Full Pack

Packaging:: Bulk

Product Status:: Obsolete

FET Type:: N-Channel

Technology:: MOSFET (Metal Oxide)

Drain to Source Voltage (Vdss):: 900 V

Current - Continuous Drain (Id) @ 25°C:: 6.5A (Ta)

Drive Voltage (Max Rds On, Min Rds On):: 10V

Rds On (Max) @ Id, Vgs:: 2.7Ohm @ 3.25A, 10V

Vgs(th) (Max) @ Id:: -

Gate Charge (Qg) (Max) @ Vgs:: 44 nC @ 10 V

Vgs (Max):: ±30V

Input Capacitance (Ciss) (Max) @ Vds:: 850 pF @ 30 V

FET Feature:: -

Power Dissipation (Max):: 2W (Ta), 37W (Tc)

Operating Temperature:: 150°C (TA)

Grade:: -

Qualification:: -

Mounting Type:: Through Hole

Supplier Device Package:: TO-220-3 Fullpack/TO-220F-3SG

1. How to order BFL4001-1EX on ODK (HK) Electronics Technology Co., Limited?

Currently, ODK (HK) Electronics Technology Co., Limited only provide peer-to-peer order processing. While you submit the RFQ, our professional agent will contact you with the competitive prices in the global market, and our agent will prompt you to finish the order if you accept our offers.

2. How does ODK (HK) Electronics Technology Co., Limited guarantee that BFL4001-1EX is from the original manufacturer or authorized agents?

We have a professional and experienced quality control team to strictly verify and test the BFL4001-1EX. All suppliers must pass our qualification reviews before they can publish their products including BFL4001-1EX on ODK (HK) Electronics Technology Co., Limited; we pay more attention to the channels and quality of BFL4001-1EX products than any other customer. We strictly implement supplier audits, so you can purchase with confidence.

3. Are the BFL4001-1EX price and inventory displayed accurate?

The price and inventory of BFL4001-1EX fluctuates frequently and cannot be updated in time, it will be updated periodically within 24 hours. And, our quotation usually expires after 5 days.

4. What forms of payment are accepted?

Wire Transfer, PayPal, Alipay, Wechat, Credit Card, Western Union, MoneyGram, and Escrow are all acceptable.

Warm Tips: Some orders in certain payment forms may require handling fee.

5. How is the shipping arranged?

Customers can choose industry-leading freight companies, including DHL, UPS, FedEx, TNT, and Registered Mail. Shipping insurance is also available.

Once your order has been processed for shipment, our salesperson will send you an email advising you of the shipping status and tracking number.

Warm Tips: It may take up to 24 hours for the carriers to display tracking information. Usually, express delivery takes 3-5 days, and registered mail takes 25-60 days.

6. What is the process for return or replacement of BFL4001-1EX?

All goods will implement Pre-Shipment Inspection (PSI), selected at random from all batches of your order to do a systematic inspection before arranging the shipment. If there is something wrong with the BFL4001-1EX we delivered, we will accept the replacement or return of the BFL4001-1EX only when all of the below conditions are fulfilled:

(1)Such as a deficiency in quantity, delivery of wrong items, and apparent external defects (breakage and rust, etc.), and we acknowledge such problems.

(2)We are informed of the defect described above within 90 days after the delivery of BFL4001-1EX.

(3)The PartNo is unused and only in the original unpacked packaging.

Two processes to return the products:

(1)Inform us within 90 days

(2)Obtain Requesting Return Authorizations

7.How to contact us to get technical supports, such as BFL4001-1EX pin diagram, BFL4001-1EX datasheet?

If you need any after-sales service, please do not hesitate to contact us.

Part Number	BFL4001-1EX	BFL4001	BFL4001-1E
Manufacturer	onsemi	onsemi	onsemi
Series	-	-	-
Package/Case	TO-220-3 Full Pack	TO-220-3 Full Pack	TO-220-3 Full Pack
Packaging	Bulk	Bag	Tube
Product Status	Obsolete	Obsolete	Obsolete
FET Type	N-Channel	N-Channel	N-Channel
Technology	MOSFET (Metal Oxide)	MOSFET (Metal Oxide)	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	900 V	900 V	900 V
Current - Continuous Drain (Id) @ 25°C	6.5A (Ta)	4.1A (Ta)	4.1A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V	10V	10V
Rds On (Max) @ Id, Vgs	2.7Ohm @ 3.25A, 10V	2.7Ohm @ 3.25A, 10V	2.7Ohm @ 3.25A, 10V
Vgs(th) (Max) @ Id	-	-	-
Gate Charge (Qg) (Max) @ Vgs	44 nC @ 10 V	44 nC @ 10 V	44 nC @ 10 V
Vgs (Max)	±30V	±30V	±30V
Input Capacitance (Ciss) (Max) @ Vds	850 pF @ 30 V	850 pF @ 30 V	850 pF @ 30 V
FET Feature	-	-	-
Power Dissipation (Max)	2W (Ta), 37W (Tc)	2W (Ta), 37W (Tc)	2W (Ta), 37W (Tc)
Operating Temperature	150°C (TA)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)
Grade	-	-	-
Qualification	-	-	-
Mounting Type	Through Hole	Through Hole	Through Hole
Supplier Device Package	TO-220-3 Fullpack/TO-220F-3SG	TO-220FI(LS)	TO-220-3 Fullpack/TO-220F-3SG
