    Infineon Technologies IR2136JTR

    !
    Obsolete 鈥?End of Life
    The manufacturer has discontinued this part. We can still source it through our global supply network 鈥?tell us the quantity you need and we will confirm availability.
    Request availability
    Part No.:
    IR2136JTR
    Manufacturer:
    Infineon Technologies
    Category:
    Gate Drivers
    Package:
    44-LCC (J-Lead), 32 Leads
    Datasheet:
    ODK (HK) Electronics Technology Co., LimitedIR2136JTR.pdf
    Description:
    IC GATE DRVR HALF-BRIDGE 44PLCC
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Inventory:Inquiry

    Please send an inquiry. Send us your inquiry, and we will respond immediately.

    Part Number
    Quantity*
    Price
    Name*
    Company*
    Email*
    Comments
    • Specifications
    • FAQ
    • Product Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Infineon Technologies
    Series:
    -
    Package/Case:
    44-LCC (J-Lead), 32 Leads
    Packaging:
    Tape & Reel (TR)
    Product Status:
    Obsolete
    Programmable:
    Not Verified
    Driven Configuration:
    Half-Bridge
    Channel Type:
    3-Phase
    Number of Drivers:
    6
    Gate Type:
    IGBT, N-Channel MOSFET
    Voltage - Supply:
    10V ~ 20V
    Logic Voltage - VIL, VIH:
    0.8V, 3V
    Current - Peak Output (Source, Sink):
    200mA, 350mA
    Input Type:
    Inverting
    High Side Voltage - Max (Bootstrap):
    600 V
    Rise / Fall Time (Typ):
    125ns, 50ns
    Operating Temperature:
    -40°C ~ 150°C (TJ)
    Grade:
    -
    Qualification:
    -
    Mounting Type:
    Surface Mount
    Supplier Device Package:
    44-PLCC, 32 Leads (16.58x16.58)
