    Boyd Laconia, LLC 7109D/TRG

    Part No.:
    7109D/TRG
    Manufacturer:
    Boyd Laconia, LLC
    Category:
    Heat Sinks
    Package:
    Datasheet:
    ODK (HK) Electronics Technology Co., Limited7109D/TRG.pdf
    Description:
    HEATSINK TO-263 (D2PK)
    Quantity:
    Payment:
    Payment
    Shipping:
    Shipping

    Inventory:9,031

    Please send an inquiry. Send us your inquiry, and we will respond immediately.

    Part Number
    Quantity*
    Price
    Name*
    Company*
    Email*
    Comments
    • Specifications
    • FAQ
    • Product Comparison
    • Tags
    Product attributes
    Attribute value
    Manufacturer:
    Boyd Laconia, LLC
    Series:
    -
    Packaging:
    Tape & Reel (TR)
    Product Status:
    Active
    Type:
    Top Mount
    Package Cooled:
    TO-263 (D²Pak)
    Attachment Method:
    SMD Pad
    Shape:
    Rectangular, Fins
    Length:
    0.763" (19.38mm)
    Width:
    1.000" (25.40mm)
    Diameter:
    -
    Fin Height:
    0.450" (11.43mm)
    Power Dissipation @ Temperature Rise:
    2.0W @ 30°C
    Thermal Resistance @ Forced Air Flow:
    3.00°C/W @ 300 LFM
    Thermal Resistance @ Natural:
    11.00°C/W
    Material:
    Copper
    Material Finish:
    Tin
